Description
The SVOLT 51.2V 106Ah A-Grade Lithium Battery is widely used in industrial, residential, commercial, and private applications. The maintenance-free construction and advanced design features make the Lithium Battery the definitive choice for a wide variety of markets – Like solar and renewable energy storage for electric vehicles, industrial equipment, medical equipment, telecommunications, TVs, and UPS systems.
– Energy: 5.427kWh
– Battery Type-Chemistry: LiFePO4
– Nominal Voltage: 51.2V
– Nominal Capacity: 106Ah
– Energy Density: 5427Wh
– Rated Energy: 5.43kWh
– Terminal Type: Fast Plug In & Plug Out
– Case Material: SPCC
– BMS Built-in: Yes
– LCD Screen
– Internal Resistance: – Efficiency – Round Trip: >99%
– Self Discharge per Month: – Max Parallel Connectors: 16Pcs
– Series Connections: Not Allowed
– Cycle Life(0.2C, 25 C @ 80% DOD): >6000 Cycles
– Discharge Temperature: -20 C to 65 C
– Charge Temperature: 0 C to 50 C
– Storage Temperature: -10 C to 30 C
– Voltage Window: 43.2V – 58.4V
– Recommended Charge Voltage: 57.6 0.20V
– Max Charge Voltage: 58.4 0.20V
– Recommended Charge Current: 50A
– Max Continuous Charge Current: 100A
– Recommended Discharge Voltage: 44.8 0.20V
– Max Discharging Voltage: 43.2 0.20V
– Max Continuous Discharge Current: 100A
– Peak Discharge Current: 150A
Size:
S-Type: 510x475x160mm – 45.6KG
R-Type: 598x360x155mm – 44.6KG
What’s In the Box:
- 1 x SVOLT 51.2V 106Ah A-Grade Lithium Battery
- 1 x Red (Positive) Battery Cable
- 1 x Black (Negative) Battery Cable
- 1 x Ethernet cable
- 1 x Manual
- 1x Wall Mount Bracket
- 1x Warranty Card
